Home / 10 - 19" Touch Screens / iiyama TF1934MC-B7X 19" Open Frame Touch Monitor

iiyama

iiyama TF1934MC-B7X 19" Open Frame Touch Monitor

Name: iiyama TF1934MC-B7X 19" Open Frame Touch Monitor
Brand: iiyama
SKU: TF1934MC-B7X
Price: 505.56 GBP
Availability: LimitedAvailability

SKU TF1934MC-B7X

3 Years Warranty Included

Key specifications

DesignOpen Frame

Diagonal19", 48cm

PanelIPS LED

Native resolution1280 x 1024 (1.3 megapixel)

Aspect ratio5:4

Panel brightness350 cd/m²

Brightness315 cd/m² with touch

Light transmittance90%

£505.56inc. VAT

£421.30 ex. VAT

Ask a question

Low stock (5 left) — order soon

Request a Quote

Bought in the UK, backed in the UKWhy it matters →

In UK stock, ships from the UK
UK manufacturer warranty
UK-based engineers
No import duty or customs charges
GBP pricing, UK VAT invoices

Est. delivery 29 Aug - 2 Sept

Return within 14 days

Installation services available Purchase orders — education customers only

Description

ProLite TF1934MC-B7X 10pt touch Open Frame monitor with IPS panel and touch through glass function ProLite TF1934MC-B7X uses Projective Capacitive touch technology, built into an eye catching bezel with edge-to-edge glass. Featuring IPS LCD screen technology, it offers exceptional colour performance and wide viewing angles, making it a perfect interactive display for Interactive Digital Signage. In addition to the superb image quality, the screen comes with an IP65 Rating, making it dust and water resistant. Equipped with a rugged bezel making it suitable for demanding environments. The ProLite TF1934MC-B7X is the ideal screen for the kiosk integrators and a solution for Interactive Digital Signage, Instore Retail, Gaming and Interactive Presentations. For ease of integration, the TF1934MC-B7X can be equipped with optional external mounting brackets (OMK1-1) making it an ideal solution f

Technical specifications

Display

PanelIPS LED

Native resolution1280 x 1024 (1.3 megapixel)

Aspect ratio5:4

Panel brightness350 cd/m²

Brightness315 cd/m² with touch

Static contrast1000:1 with touch

Touch technologyprojective capacitive

Touch points10 (HID, only with supported OS)

Touch methodstylus, finger, glove (latex)

Touch interfaceUSB

Connectivity

Colour support16.7mln

Analog signal inputVGA x1

Digital signal inputHDMI x1DisplayPort x1

OSD languagesEN, DE, FR, ES, IT, CN, JP

Power & Physical

VESA mounting100 x 100mm

Product dimensions W x H x D416 x 344 x 46.5mm

Box dimensions W x H x D16.4 x 13.5 x 1.8mm

Weight (without box)4.4kg

General

DesignOpen Frame

Diagonal19", 48cm

Light transmittance90%

Response time (GTG)14ms

Viewing zonehorizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°

Horizontal Sync31.4 - 80kHz

Viewable area W x H376.5 x 301.1mm, 14.8 x 11.9"

Pixel pitch0.294mm

Bezel colour and finishblack, matte

Through-Glass6mm

Palm rejectionyes

Extraanti-fingerprint coating, touch through-glass

Water and dust protectionIP65 (front)

OSD key lockyes

Control buttonsMenu, Scroll up/ Brightness, Scroll down/ Contrast, Select, Power

User controlspicture (contrast, brightness, H.position, V.position, phase, clock, auto adjust), advanced (color temp., sharpness), OSD (time out, position, H-position, V-position, touch switch), option (reset, language, source select, display mode, factory)

Plug&PlayDDC2B

Orientationlandscape, portrait, face-up

Cablespower, USB, HDMI, DP

Guidesquick start guide, safety guide

OtherAC adapter, Touch Panel Driver Disk (CD-ROM)

Cable coveryes

Power supply unitexternal

Power supplyDC 12 V

Power usage21W typical, 1.5W stand by, 1.5W off mode

RegulationsCE, EAC, RoHS support, ErP, WEEE, cULus, REACH

Energy efficiency class (Regulation (EU) 2017/1369)F

REACH SVHCabove 0.1%: Lead

EAN code4948570118403

Mounts / Stands / BracketsOMK1-1

Related productsRC TOUCHV01, OMK1-1

User manualTF15_17_1934MC-B7X-usermanual-e.pdf

Technical specificationProLite TF1934MC-B7X - gb_en.pdf

DrawingTF1934MC_drawing.pdf

EU Energy LabelTF1934MC-B7X EU Energy Label pdf data(392527).pdf

UK Energy LabelTF1934MC-B7X UK Energy Label pdf data(392527).pdf

CETF1934MC-7XC CE DoC.pdf

Documents

iiyama TF1934MC-B7X datasheet
